Reflex Silver Mk5 Golf GTI

[JamieKirk95]

So today I managed to get some time to go over the interior and post some pictures of the inside.

IMG_5400 by jamie kirk, on Flickr

IMG_5402 by jamie kirk, on Flickr

IMG_5403 by jamie kirk, on Flickr

IMG_5404 by jamie kirk, on Flickr

IMG_5405 by jamie kirk, on Flickr

IMG_5406 by jamie kirk, on Flickr

One of my favourite things about the car, the seats;

IMG_5407 by jamie kirk, on Flickr

I also managed to fit my Euro Cup Holder around a month ago, properly happy with this mod

IMG_5409 by jamie kirk, on Flickr

I then gave the car a quick wash

IMG_5418 by jamie kirk, on Flickr

IMG_5419 by jamie kirk, on Flickr

IMG_5421 by jamie kirk, on Flickr

IMG_5422 by jamie kirk, on Flickr

Thanks

Jamie

[JamieKirk95]

Took the car into VW today, hopefully should be done by next Thursday. In the mean time i've got this;

IMG_5425 by jamie kirk, on Flickr

IMG_5426 by jamie kirk, on Flickr

IMG_5427 by jamie kirk, on Flickr

Jamie

[shoaybmakda]

Better than what I got - I had a VW Up! And they always give me a manual car even though I request an auto. Hate driving manuals!

The Up did have beats audio in which I've not seen before (my standard golf sound system sounded better if I'm honest!)

[JamieKirk95]

Haha its a nice car really, perfect for driving round town but think it would struggle for power on fast roads/motorways. I really like the bluetooth audi and mfsw and has got me thinking!

[JamieKirk95]

The next piece of the puzzle arrived last week, a genuine cruise control stalk. Will be getting this fitted and coded around March time.

IMG_5219 by jamie kirk, on Flickr

IMG_5220 by jamie kirk, on Flickr

IMG_5221 by jamie kirk, on Flickr

Cleaned up using Britemax Grime Out

IMG_5222 by jamie kirk, on Flickr

IMG_5223 by jamie kirk, on Flickr

Jamie

[Pagejack]

Great write up so for dude,mines going in Saturday for an identical service so was an interesting read.

All the best

[JamieKirk95]

Thanks mate it's coming along really and sounds good

[JamieKirk95]

So today I went to VW to pick the car up after having its front wings replaced under their bodywork guarantee. When I first got there I spotted the car so had a proper look round the car before going in.

I must say they have done a top job with the car and am so happy with it, they have replaced the two wings with brand new parts, modified the new sponge on the inside so its not exposed and then run a silicone bead around it to prevent it from happening again. They have also blended the paint so is a really good match and you wouldn't be able to tell.

I then went into the dealership and was greeted by one of the bodyshop supervisors, he asked me if i'd had a look round the car and said yes, he then got me to sign the warranty sheet saying the work they had done to the car, I have got a copy of this and will keep for my own record to show the work has been done. We swapped keys he had a quick look round the polo then that was it I was off.

I am so happy with the work they've done it was worth the 8 month and at no point was I asked for a single contribution by VW for the work.

The pictures don't do them justice but heres a few

IMG_5444 by jamie kirk, on Flickr

IMG_5445 by jamie kirk, on Flickr

IMG_5446 by jamie kirk, on Flickr

IMG_5447 by jamie kirk, on Flickr

IMG_5448 by jamie kirk, on Flickr

IMG_5449 by jamie kirk, on Flickr

IMG_5450 by jamie kirk, on Flickr

IMG_5451 by jamie kirk, on Flickr

IMG_5452 by jamie kirk, on Flickr

IMG_5453 by jamie kirk, on Flickr

IMG_5454 by jamie kirk, on Flickr

IMG_5455 by jamie kirk, on Flickr

IMG_5456 by jamie kirk, on Flickr

O/S Before

IMG_5412 by jamie kirk, on Flickr

O/S After

IMG_5446 by jamie kirk, on Flickr

N/S Before

IMG_5416 by jamie kirk, on Flickr

N/S After

IMG_5453 by jamie kirk, on Flickr

And finally

IMG_5457 by jamie kirk, on Flickr

IMG_5458 by jamie kirk, on Flickr

Jamie

[JamieKirk95]

When I got the car I noticed that the interior grab handles were quite worn and looking at the how to's on mk5gti.co.uk I decided that this was a job i'd like to do. When I put an order in for my service bit's from TPS I also ordered the three trim parts I needed. With this I also decided to change the headlight switch, window switches and fuel switch to the newer mk6 type.

So having got the car back from VW today I decided to get them swapped over.

IMG_5436 by jamie kirk, on Flickr

Headlight Switch

IMG_5461 by jamie kirk, on Flickr

First off, in the off position push the switch inwards

IMG_5466 by jamie kirk, on Flickr

Twist to the automatic lights position

IMG_5467 by jamie kirk, on Flickr

Then simply pull out and unclip the electrical connecter

IMG_5468 by jamie kirk, on Flickr

IMG_5469 by jamie kirk, on Flickr

Old vs. New

IMG_5470 by jamie kirk, on Flickr

Fitted

IMG_5475 by jamie kirk, on Flickr

IMG_5472 by jamie kirk, on Flickr

IMG_5473 by jamie kirk, on Flickr

Drivers Side

Before

IMG_5476 by jamie kirk, on Flickr

IMG_5477 by jamie kirk, on Flickr

IMG_5478 by jamie kirk, on Flickr

Comparison

IMG_5479 by jamie kirk, on Flickr

IMG_5480 by jamie kirk, on Flickr

IMG_5481 by jamie kirk, on Flickr

IMG_5482 by jamie kirk, on Flickr

Disconnect switches

IMG_5483 by jamie kirk, on Flickr

IMG_5484 by jamie kirk, on Flickr

New Switches

IMG_5485 by jamie kirk, on Flickr

IMG_5486 by jamie kirk, on Flickr

After

IMG_5487 by jamie kirk, on Flickr

IMG_5488 by jamie kirk, on Flickr

IMG_5489 by jamie kirk, on Flickr

Passenger Side

To start we used the trim removal tool to separate the two plastic pieces, the top one is held in by two t30 screws, we removed these and then thought the handle would then come away...

IMG_5490 by jamie kirk, on Flickr

IMG_5491 by jamie kirk, on Flickr

However, the handle is also held in by two screws at the back so it meant we would have to remove the door card to gain access.

The replacement

IMG_5492 by jamie kirk, on Flickr

IMG_5493 by jamie kirk, on Flickr

IMG_5494 by jamie kirk, on Flickr

We then took the door card off, the door card itself is held in place by 4 t20 screws one on the side and three along the bottom

IMG_5495 by jamie kirk, on Flickr

IMG_5496 by jamie kirk, on Flickr

We then lifted up the door card

IMG_5498 by jamie kirk, on Flickr

I then located the two t20 screws to undo, the handle then came away and we reversed the process

IMG_5499 by jamie kirk, on Flickr

IMG_5502 by jamie kirk, on Flickr

IMG_5503 by jamie kirk, on Flickr

Door card back on

IMG_5504 by jamie kirk, on Flickr

After

IMG_5506 by jamie kirk, on Flickr

IMG_5507 by jamie kirk, on Flickr

IMG_5508 by jamie kirk, on Flickr

Comparison

IMG_5509 by jamie kirk, on Flickr

Fuel Switch

I don't have many photos of this as it was a right pig of a job to do:lol:

Before

IMG_5510 by jamie kirk, on Flickr

IMG_5511 by jamie kirk, on Flickr

Comparison

IMG_5512 by jamie kirk, on Flickr

IMG_5513 by jamie kirk, on Flickr

Jamie

[Octoparrot]

Really nice work there! Any chance you could post up the part numbers and prices for the switches as it's something I'm considering doing myself

[JamieKirk95]

Hi mate, yeah no worries.

1K3868050C 75R - cover

1K0868039B 75R - cover

1K0867179D 75R - Handle

I bought the lights here:

http://cgi.ebay.co.uk/ws/eBayISAPI.dll?ViewItem&item=232232538652#ht_1223wt_1222

[sean.smithy94]

Looking good with the new wings, interior is looking much nicer too, I intend on changing the switches and grab handles, springs next?

[JamieKirk95]

Looking good with the new wings, interior is looking much nicer too, I intend on changing the switches and grab handles, springs next?

Thanks mate, yeah i'd say it's definitely worth it! Haha maybe not just yet, i'd like an rcd510 next I think then around summertime get the wheels redone then maybe some springs but don't know whether to get some depo headlights.

[Octoparrot]

Thanks for the part numbers, do the switches feel like quality items?

[JamieKirk95]

No worries, yeah I'm happy with them really as many other users are on here, I think they are worth the money mate!
