Author Topic: Caliper paint  (Read 5889 times)

Offline Andy

  • Admin
  • Just look at my post count
  • *
  • Thank You
  • -Given: 39
  • -Receive: 443
  • Posts: 10929
    • Email
Re: Caliper paint
« Reply #15 on: June 09, 2014, 04:50:59 pm »
yes did mine in hammerite also

Offline toosmiles

  • Won't Shut up.
  • *****
  • Thank You
  • -Given: 22
  • -Receive: 18
  • Posts: 635
    • Email
  • My Ride: http://www.mk5golfgti.co.uk/forum/index.php/topic,92286.0.html
Re: Caliper paint
« Reply #16 on: June 09, 2014, 04:54:30 pm »
a very good clean process first like xjay said then hammerite smooth over the weekend


not perfect but alot better
Golf R mk6 R-tech tuned GTX3071r

Offline SurreyED30

  • Just look at my post count
  • ******
  • Thank You
  • -Given: 37
  • -Receive: 32
  • Posts: 1362
Re: Caliper paint
« Reply #17 on: June 09, 2014, 06:03:40 pm »
Look great mate  :happy2:
Edition 30 build No:692 Revo stage 2 SOLD
Edition 30 build No:440 Stage 1 SOLD

Offline th3_f15t

  • Just look at my post count
  • ******
  • Thank You
  • -Given: 66
  • -Receive: 183
  • Posts: 2676
  • My Ride: http://www.mk5golfgti.co.uk/forum/index.php/topic,101525.0.html
Re: Caliper paint
« Reply #18 on: June 12, 2014, 02:07:09 pm »
Sorry to hi-jack, but I may be doing a similar job on the girlfriends GTI. So as far as method goes;

1. Clean off all dirt and dust with brake cleaner and spirits
2. Wire brush then sand to remove all loose paint and leave a clean, rough surface for the paint to bond
3. Paint first coat and leave for 24 hours to set properly. Apply layers until a smooth finish is obtained

Anything I've missed?

Moving over to Flickr, sorry for the broken picture links!

Offline xjay1337

  • Just look at my post count
  • ******
  • Thank You
  • -Given: 15
  • -Receive: 377
  • Posts: 4916
  • My Ride: http://www.mk5golfgti.co.uk/forum/index.php/topic,88399.0.html
Re: Caliper paint
« Reply #19 on: June 12, 2014, 02:14:58 pm »
Why would you wait 24 hrs after first coat before applying additional ones?

Offline rich83

  • Just look at my post count
  • ******
  • Thank You
  • -Given: 165
  • -Receive: 802
  • Posts: 13444
    • MK5 Golf GTI
  • My Ride: https://www.mk5golfgti.co.uk/forum/index.php/topic,19740.0.html
Re: Caliper paint
« Reply #20 on: June 12, 2014, 02:45:05 pm »
Foliatec...



2/3 coats

Offline DamoP

  • Just look at my post count
  • ******
  • Thank You
  • -Given: 5
  • -Receive: 115
  • Posts: 2452
  • 2007 Edition 30 number 1242
    • Email
  • My Ride: http://www.mk5golfgti.co.uk/forum/index.php/topic,86073.0.html
Re: Caliper paint
« Reply #21 on: June 12, 2014, 03:33:47 pm »

hammerite smooth 2/3 coats
MDI Armrest & Glovebox kits
MDI looms , iPod, USB & lightening Iphone 5 leads
Armrests, cloth and leather
Retro fit Armrest 6 CD changer/Ipod dock kits

Offline lukemk5gti

  • Just look at my post count
  • ******
  • Thank You
  • -Given: 28
  • -Receive: 118
  • Posts: 1845
    • Email
  • My Ride: http://www.mk5golfgti.co.uk/forum/index.php/topic,89715.msg907250.html#msg907250
Re: Caliper paint
« Reply #22 on: June 13, 2014, 12:26:56 pm »
Sorry to hi-jack, but I may be doing a similar job on the girlfriends GTI. So as far as method goes;

1. Clean off all dirt and dust with brake cleaner and spirits
2. Wire brush then sand to remove all loose paint and leave a clean, rough surface for the paint to bond
3. Paint first coat and leave for 24 hours to set properly. Apply layers until a smooth finish is obtained

Anything I've missed?

I literally painted my calipers last night and found this thread this morning. I used spray paint as it gives a more even finish.

Steps as follows:
1) Apply brake cleaner and leave to penetrate
2) Scrape flakey paint off with flat screwdriver or wire brush and remove quick release spring from front calipers only.
3) Clean over entire surface with brillo pad
4) Sand entire brake down with sandpaper, I started with 600grit.
5) Mask over entire area and don't forget the middle of the caliper or you'll spray the discs too.
6) When you're ready to spray give it one last decent spray with brake cleaner so there's no lingering dust.
7) Spray over with a very light coat of ted temperature resistant paint. I used 650degree paint. Remember if you put on too much it will form droplets so go light.
8) The temperature resistant paint dries very quickly and I parked my car to face the sun. Apply 2/3 coats until you're happy.
9) Start applying clear laquer spray paint to calipers. I used 4 coats of very light spray.
10) Fit the quick release brake spring back into the front caliper. Do it very carefully or you'll scratch your brand new calipers!!!!!!

Note: While I was waiting for my paint coats to dry I was repairing the light scuffs on my alloys using your typical alloy repair kit. I don't know if I was lucky with the paint but each coat dried within 20minutes facing the sun at about 22degrees.

I've taken a load of photos of each stage so give me a shout if you need any help!

Offline nicky

  • Always Involved
  • ****
  • Thank You
  • -Given: 5
  • -Receive: 5
  • Posts: 293
    • Email
Re: Caliper paint
« Reply #23 on: June 13, 2014, 12:48:12 pm »
I used Japlac


Offline th3_f15t

  • Just look at my post count
  • ******
  • Thank You
  • -Given: 66
  • -Receive: 183
  • Posts: 2676
  • My Ride: http://www.mk5golfgti.co.uk/forum/index.php/topic,101525.0.html
Re: Caliper paint
« Reply #24 on: June 13, 2014, 01:18:32 pm »
Why would you wait 24 hrs after first coat before applying additional ones?

Never used hammerite paint so assumed it'd need drying time between coats.

Moving over to Flickr, sorry for the broken picture links!

Offline DanMaytee

  • Always Involved
  • ****
  • Thank You
  • -Given: 1
  • -Receive: 13
  • Posts: 189
    • Email
Re: Caliper paint
« Reply #25 on: June 13, 2014, 02:21:08 pm »
I used Hammerite Hammered Blue.  I gave them a really quick go over with a wire brush (literally 20 secs on each), gave them all one coat then another coat 30 minutes later.  Still look good to this day :)


Offline Monkey10

  • Taking part
  • ***
  • Thank You
  • -Given: 1
  • -Receive: 5
  • Posts: 49
Re: Caliper paint
« Reply #26 on: June 15, 2014, 09:03:04 am »
Hammerite for me too. Rubbed down to bare metal as paint was very flakey, 2 coats of paint with a brush. Looks nice and neat and a lot better now not faded and peeling. Fronts to do next weekend!

Offline JC88

  • Always Involved
  • ****
  • Thank You
  • -Given: 21
  • -Receive: 6
  • Posts: 219
Re: Caliper paint
« Reply #27 on: June 16, 2014, 10:21:08 pm »
Heard some mixed responses from this recently but don't know if any of you guys can shine any light on this, I've given some calipers a couple of coats of hammerite smooth and theres a couple of spots which will need rubbing back and whatnot :S but does anyone know if you can effectively wet sand the hammerite back a bit and then clear coat it with a VHT lacquer? Some googling has led to it possibly bubbling and wrinkling the hammerite..... Anyone able to advise? :S
