THS 2.0 T FSI Intercooler
THS 2.0 T FSI IntercoolerTHS 2.0 T FSI Intercooler

2.0TFSI platform cars have a front mounted intercooler as standard, which provides adequate cooling for a stock car. However once boost levels are increased, either by ECU remapping or the introduction of a bigger turbo, stock coolers struggle to maintain low intake temperatures.

Once the air intake temperature gets too hot, the engine ECU will retard the timing and lower boost levels to maintain engine's safety.
The stock cooler forms the hangers for both the radiator and air conditioning condenser, due to this up rated cooler designs fall into one of two categories.

Keep a stock cooler in place and add additional cooling.

A new cooler which retains all the hangers for the radiator and a/c condenser.
Whilst offering more efficient cooling. and reduced pressure drop

As the stock cooler have its limitations, a small2 core and plastic end tanks
(Note Audi S3 cooler has a slightly larger core, with aluminium tanks, but restricted inlet / outlets)

THS concluded for a number of reasons that a new high efficiency bar and plate cooler as a direct replacement for the stock cooler offers best solution and results.

No extra pipe work, keeping un-cooled air volume to a minimum, reducing turbo lag.

Removal of restrictive OEM end tanks, restrictive inlet/outlets and core.

Lower pressure drop.

No bumper trimming required.

THS concluded for a number of reasons that a new high efficiency bar and plate cooler as a direct replacement for the stock cooler offers best solution and results.
No extra pipe work, keeping un-cooled air volume to a minimum, reducing turbo lag.
Removal of restrictive OEM end tanks, restrictive inlet/outlets and core.
Lower pressure drop.
No bumper trimming required.


Added by MC71, on 2014-10-21 19:07:18
from 1 review.
THS FMIC
by MC71, on 2014-10-21 19:19:42
A worthwile mod even on a standard car BUT definitely needed on modified/tuned car. Not the cheapest but one of the best and biggest.
